กล้องวงจรปิด Hikvision 2MP Vari-focal Motorized DS-2CD2721G0-IZ เป็นกล้องระบบ IP ความละเอียด 2MP ให้ภาพคมชัดระดับ Full HD มาพร้อมเลนส์ Vari-focal แบบ Motorized สามารถปรับระยะซูมและมุมมองภาพได้จากระยะไกล รองรับอินฟราเรด (IR) สำหรับการมองเห็นในเวลากลางคืน และมาตรฐานกันน้ำกันฝุ่น IP67 เหมาะสำหรับติดตั้งทั้งภายในและภายนอกอาคาร เชื่อมต่อกับ NVR และดูภาพผ่านมือถือได้สะดวก
- กล้องวงจรปิด รุ่น DS-2CD2721G0-IZ
- ความละเอียด 2 ล้านพิกเซล (2MP)
- รูปทรงโดม Dome Camera
- ขนาดเลนส์ 2.8mm-12mm
- ขนาดเซนเซอร์ 1/2.8″
- ค่า(LUX) 0.002
- การบีบอัดไฟล์ H.265+
- ระยะอินฟาเรด IR 40m
- การย้อนแสง 120 dB WDR
- มีอินเทอร์เฟซเสียงและสัญญาณเตือนภัยให้ใช้งานได้
- มาตรฐานการป้องกัน IP66 และ IK10
Camera | |
| Image Sensor | 1/2.8″ Progressive Scan CMOS |
| Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.002 Lux @ (F1.4, AGC ON),B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100, 000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
Lens | |
| Lens Type | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | 2.8 mm, to 12 mm: horizontal FOV 113° to 31°, vertical FOV 58° to 18°, diagonal FOV 138° to 36° |
| Lens Mount | Ø14 |
| Iris Type | Fixed |
| Aperture | F1.4 |
| Depth of Field | 0.5 m to ∞ |
DORI | |
| DORI | 2.8 to 12 mm: Wide: D: 44.1 m, O: 17.5 m, R: 8.8 m, I: 4.4 m Tele: D: 137.9 m, O: 54.7m, R: 27.6 m, I: 13.8m |
Illuminator | |
| Supplement Light Range | Up to 40 m |
| IR Wavelength | 850 nm |
| Video | |
| Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360 ) 60 Hz: 30 fps (640 × 480, 640 × 360 ) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360), *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264, *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR,VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio | |
| Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
Image | |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancemen | BLC, HLC, 3D DNR |
| SNR | ≥ 52 dB |
| Privacy Mask | Yes |
Interface | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Audio | 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
| Alarm | 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A) |
| Reset Key | Yes |
Deep Learning Function | |
| Face Capture | Yes |
General | |
| Power | 12 VDC ± 25%, 0.88 A, max. 10.5 W,two-core terminal block,reverse polarity protection, PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W |
| Material | Metal |
| Dimension | Ø153.5 mm × 133.1 mm (Ø6.0 × 5.2\”)” |
| Package Dimension | 244 mm × 174 mm × 173 mm (9.6″ × 6.9″ × 6.8″) |
| Weight | Approx. 830 g (1.9 lb.) |
| With Package Weight | Approx. 1710 g (3.8 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Heartbeat,anti-flicker,mirror,flash log,password reset via email,pixel counter |
Approval | |
| Protection | IP66: IEC 60529-2013;IK10: IEC 62262:2002 |
